CentIoT - Sound Recordable Chip IC - Voice Music Talking Recorder Module - 8ohm Speaker - for Electronic Gift Greeting Card - ISD1806B 6 Seconds

Brand: CentIoT

Features:

• CHIP: ISD1806B 6S; Zero-power message storage Eliminates battery backup circuits 100-year message retention (typical) 100,000 record cycles (typical) On-chip oscillator No algorithm development required
• Voltage: 3-4.5V; 0.5 µA standby current (typical)
• Driving Loudspeaker: 0.25-2W/8 ohm
• Easy-to-use single-chip, single-message voice record/playback solution
• Automatic power-down mode Enters standby mode immediately following a record or playback cycle On-chip 8Ω speaker driver

Format: Digital Sound

PartNumber: AU089-ISD1806-WBC

Details: ISD1800 provides high-quality, single chip, single-message, record/playback solution with user-selectable durations of 6 to 16 seconds. The CMOS devices include an on-chip oscillator (with external control) , microphone preamplifier, automatic gain control, anti-aliasing filter, multilevel storage array, smoothing filter, and speaker amplifier. A minimum record/playback subsystem can be configured with a microphone, a speaker, several passive components, two push buttons, and a power source. Recordings are stored in on-chip nonvolatile memory cells, providing zero-power message storage. Voice and audio signals are stored directly into memory in their natural form, providing high-quality, solid-state voice reproduction.

Model: AU089-ISD1806-WBC

Binding: Electronics

Item Condition: New
