CentIoT - Lifepo4 6S/7S/13S 24V 36V 48V - 25A BMS Battery Management System PCM PCB - for 6, 7 and 13 Series Lifepo4 Lithium Ion Phosphate Battery Pack for ebike erikshaw

Brand: CentIoT

Features:

• Suitable for 6, 7 and 13 string lithium iron phosphate lifepo4 battery series combination; Module Output Voltage: 24V @6S; 36V @ 7S 48V @ 13S; Over Discharge Protection Current: 40A; Charging Current: 18A; Charging voltage: 24V @ 6S/7S; 36V to 48V @ 13S
• Over-Charging Voltage: 4.25V; OverCharge Recovery Voltage: 4.19V; Overcharge Voltage Protection Delay: 1000ms
• Over Discharge Voltage: 2.8V; Over-discharge recovery voltage: 3V; Over-discharge voltage protection delay: 140ms
• Over-dishcarge protection current: 60A; Split Discharge Current (continuous): 26A; Same Port Discharge Current (Continuous): 18A; Overcurrent protection recovery: Disconnect load release
• With Short circuit protection Overcharge protection Over-discharge protection Overcurrent protection, Remove protection condition automatic recovery, without activation

PartNumber: BM100-6S7S13S-25A-LIFEPO4

Release Date: 13-06-2019

Details:

A battery management system (BMS) is any electronic system that manages a rechargeable battery (cell or battery pack), such as by monitoring its state, calculating secondary data, reporting that data, protecting the battery, controlling its environment, and balancing it.

EAN: 4604046158747

Model: BM100-6S7S13S-25A-LIFEPO4

Binding: Electronics

Item Condition: New
