CentIoT - IP5328P Dual USB 18650 Battery Charger treasure Tpye-c 3.7V to 5V 9V 12V Step up Fast Quick Charger Circuit Board QC2.0 QC3.0

Brand: CentIoT

Features:

• Input: Type C or Micro USB fast charging capable
• Output: 5V-3.1A, 7V-2.4A, 9V-2.0A, 12V-1.5A | Output Interface: Dual USB PD output and Type C PD
• Chipset: IP5326P; 4 onboard SMD LED to display battery charge level
• Output Interface: USBA + USBA + TYPE-C support fast charge output (see protocol specification fast charge)
• Overcharge protection | Overdischarge protection | Overcurrent protection

PartNumber: IP5328P

Details: Module mobile power core use IP5328P IC, four gold-plate, optimized layout, support for multiple protocols fast charging, fast charging bidirectional 18W(3V x 5A), can support a total charging port 4: 2 USB-A output interface, an USB-C interface, Micro USB interface, four interface supports fast-charge, wherein two support USB-A port QC3.0, FCP, AFC, MTK, SFCP fast charge output power of up to 18W; apple support, Samsung, BC1.2 agreement. USB-C port supports USB PD bi-directional fast-charge, compatible with FCP, AFC, SFCP fast charge input and QC3.0, FCP, AFC, MTK, SFCP fast charge output. MicroUSB support FCP, AFC, SFCP fast charge input. M/br> Note: IP5328P do not support charging the battery and phone at the same time, the output discharge port will be closed while charging the battery.

Model: IP5328P

Item Condition: New
