CentIoT - DC 0-25V Voltage Sensor tester Module Test Electronic Bricks

Brand: CentIoT

Color: Red

Features:

• Voltage input range: DC 0 - 25V
• Voltage detection range: DC 0.02445V - 25V
• Voltage analog resolution: 0.00489V
• Output Interface : "+ " connected 5/3.3V, "-" connected GND, "s" connected AD pins
• DC input interface : red terminal positive with VCC, negative with GND

PartNumber: SE208-VOLT-SEN-0-25V

Release Date: 21-07-2020

Details: This module design is based on resistive divider principle, that reduces the interface terminal input voltage by 5 times, Arduin support analog input voltage up to 5V, so the input voltage of the volt ...

UPC: 679043312588

EAN: 0679043312588

Model: SE208-VOLT-SEN-0-25V

Binding: Electronics

Item Condition: New
