Description
Brand: CentIoT
Color: Green
Features:
- Charging voltage range:: 54.6V; Maximal continuous charging current: 20A
- Over-discharge recovery voltage: 2.5v ± 0.05v, over-discharge-delay-time: 144ms
- Maximum Continuous Discharging current: 20A, Maximum Working current: 20A, Max Instantaneous Discharge Current: 100A; Static current: less than 8uA;
- Short circuit protection: protect and automatic recovery, Over discharge protection: yes, over-current-protection: yes
- Refer Datasheet in Images for more information
PartNumber: BM042
Details: NOTE: 1) This board is suitable for EBike and electric Car, also suitable for high power electronic tools, like screwdrier and drill. Features: 1) High-accuracy voltage detection circuit; 2) Terminal of the charger using high voltage device; 3) Built-in three-stage over-current detection circuit (over-current 1, over-current 2, or load short circuit); 4) MOS transistor can control the battery charge and discharge; 5) low standby current consumption.
EAN: 4604046155555
Model: BM042-13S20A
Item Condition: New
